AV ALVIUM G1-131C-CH-S

SKU#:

57614

Reinventing the embedded vision camera: The Allied Vision Alvium series is an innovative embedded camera platform that addresses the limitations associated with current cameras for embedded applications and offers system designers a previously unknown level of freedom.

Add to cart to request price

Bénéficiez de nos services à valeur ajoutée que nous adaptons à vos besoins individuels.

Request prices

Errors and omissions excepted. Our General Terms and Conditions apply. We exclusively supply corporate customers.

About This Series

* Sensor: CMOS sensors from 0.5 to 21 megapixels * Features: powered by ALVIUM technology, designed for embedded vision with ARM board compatibility * Lens mount: C-, S-, and CS-mount option * Interface: 4-lane MIPI CSI-2 interface with D-PHY up to 6 Gbit/s, USB3 Vision compliant USB 3.1 Gen 1 interface * Miscellaneous: single PCB design, bare board and front housing options

Resources

Product Features

Attributes

Active sensor size (horizontal, mm)

6.78

Active sensor size (vertical, mm)

5.43

Bit depth

8; 10

Dimension (depth, mm)

Dimension (height, mm)

Dimension (width, mm)

Frame rate (Hz)

Horizontal res. (Px)

1280

Housing

closed housing

Interface configuration

1 GigE

Interface

Gigabit Ethernet

Lens mount

C-Mount

Manufacturer

Allied Vision

Numbers of connectors (Video)

Pixel size (µm)

5.3

Resolution (MP)

1.3

Scan type

area

Sensor format

1/1.8"

Sensor model

EV76C560

Sensor size diagonal (mm)

8.69

Sensor type

CMOS

Shutter type

Rolling shutter

Wavelength range

Colour; Visible

Vertical res. (Px)

1024

Weight (kg)

0.065
